Payment via a store

This tutorial will guide you step by step to generate store payment references, in order to receive payments through convenience stores.

Notice: You can get notifications minutes after your customer makes the payment.

Process to make store charges:

Flow to make payments in stores

Steps:

Customer completes the buying by selecting store charge as payment method
Send a store charge request to Openpay
Create a payment order for your customer with the returned information
Customer goes to store and pays for the order
Openpay receives and validates the payment
Openpay notifies the payment to your server

This tutorial you can see steps 2 and 3, for step 6 details please check notifications section

Create a charge (Step 2)

To receive a payment in a store you need to generate a barcode with the reference with which your customer can pay at the store.

To do this you must make a request to our API as follows:

Note: The maximum amount allowed for such charges is $ 9,999.00 COP

If the request is successful you will receive an answer with the reference number generated and the barcode URL so you can create your receipt.

Response:

{
    "id": "trgklldjutbqv9gqzyn9",
    "authorization": null,
    "operation_type": "in",
    "method": "store",
    "transaction_type": "charge",
    "status": "in_progress",
    "conciliated": false,
    "iva": "16",
    "creation_date": "2019-11-04T11:13:16-06:00",
    "operation_date": "2019-11-04T11:13:16-06:00",
    "description": "Cargo inicial a mi cuenta de store",
    "error_message": null,
    "order_id": "oid-20191104111316",
    "payment_method": {
        "type": "store",
        "reference": "1010101389264548",
        "barcode_url": "https://sandbox-api.openpay.co/barcode/1010101389264548?width=1&height=45&text=false"
    },
    "currency": "COP",
    "amount": 226,
    "customer": {
        "name": "Ambrosio",
        "last_name": "Medina",
        "email": "ambrosio.medina@company.co",
        "phone_number": "571983873734",
        "address": null,
        "creation_date": "2019-11-04T11:13:16-06:00",
        "external_id": null,
        "customer_address": {
            "department": "Medellín",
            "city": "Antioquia",
            "additional": "Avenida 7r bis #144-28 Apartamento 423",
            "country": "CO"
        },
        "clabe": null
    }
}

Sandbox: You can simulate the payment from the dashboard, so you can get a payment notification on your system via a Webhook.

Production: The payment notification is done in real time, that is when your customer makes the payment at the store you will receive a Webhook and the balance in your account will be increased.

For more information see the charges reference

Create a payment receipt (Step 3)

Openpay offers the possibility of obtaining a payment receipt with the necessary information so that your client can make the payment in store, to reach it, it is enough to structure a compound route as follows:

{DASHBOARD_PATH}/paynet-pdf/{MERCHANT_ID}/{REFERENCE}

Sandbox: {DASHBOARD_PATH} = https://sandbox-dashboard.openpay.co

Producción: {DASHBOARD_PATH} = https://dashboard.openpay.co

{MERCHANT_ID} = your merchant id

{TRANSACTION_ID} = value of payment_method.reference field, that the transaction object returned when the charge was created

Create Custom Payment Receipt (Step 3.1 Optional)

Basically you can create your receipt with any design and colors, but it should include:

Name of the service to pay
- Store Payment
Reference:
- Value of the reference field
Barcode:
- Image of the barcode_url field
Amount Due:
- Value of the amount field

Notes:

Make sure your integration meets the version compatibility requirements more info

Implement Notifications to know the status of payments in real time
